4000 Series Fresh Tank Sensor Assembly

About this product

Brand: Sensata
Model: P356-1.3G-E1A
Type: Low-Pressure Differential/Gage Transducer

Description:
The Sensata water sensor is a sophisticated low-pressure differential/gage transducer designed for precise measurement applications. Utilizing Kavlico’s proven ceramic capacitive technology, this transducer is housed in durable brass, ensuring long-term stability and excellent performance. It operates within a pressure range of 0 to 1.3 PSI, making it suitable for various industrial applications such as water tower levels, wastewater systems, and pneumatic controls.

In the 4000 series vans, the Fresh Tank Sensor Assembly will be prewired and sealed, ready for installation when you need to change out the freshwater sensor assembly on the freshwater tank drain line. This assembly features prewired Deutch connections and housings with the sensor connection itself sealed and ready for install.

Features:

• Pressure Range: 0 to 1.3 PSI
• Main Pressure Fitting: 1/4-18 NPT
• Differential Reference Port: 1/4-inch hose fitting
• Repeatability and Hysteresis: Superior performance
• EMI/RFI Protection: Ensures reliable operation in environments with electrical interference
• Linear Amplified Output: Voltage range from 0.5 to 4.5 VDC
• Temperature Compensation: Operates over a wide range from -30°C to +100°C
• Protection Features: Over-voltage, reverse polarity, and short circuit protection
• Durability: Life expectancy of ten million cycles with outstanding shock and vibration performance
• Prewired and Sealed: Ready for installation
• Deutch Connections and Housings: Ensures secure and reliable connections
• Sealed Sensor Connection: Ready for install

Compatible Van Series:

• 4000 series vans

Benefits:
The Sensata P356-1.3G-E1A is a robust and dependable choice for accurate pressure measurement, providing long-term stability and excellent performance in various industrial applications. The Fresh Tank Sensor Assembly ensures easy and reliable installation of the freshwater sensor assembly on the freshwater tank drain line, providing secure and watertight connections.
